CTV-Pro Series

CTV-Pro Series

4K Standard Commercial AIO LED TV Display ( 163” 216” )


VIDEO

Various Type for Different Scenarios

Package : SMD/Mini/COB
Size: 135” 163” 216”
Pixel Pitch: 0.7mm, 0.9mm, 1.2mm,1.5mm,1.8mm,2.5mm

CTV-Pro Series
Vivid & Broad Visual Experience

3840x2160 4K High Definition
High Contrast Ratio:20000:1, ＞95% brightness uniformity
0.08 Chromatic uniformity, standard 100% bt709 wide color gamut
High Dynamic Range(HDR): display images more closely resemble what the human eye can perceive

CTV-Pro Series
Best Audio Perfermance

Built-in 2x20W full-band custom speaker, 82dB high sensitivity.120Hz box tuning, 20-20KHz ultra-wide frequency response rangeleft and right channel stereo.

CTV-Pro Series
Various Interface

USB x 3  |  HDMI in x 5  |  HDMI out x 1  |  RS232 x 1
Audio out x 1  |  Audio in x 1  |  S/PDIF out x 1  |  Type-C in x 1  |  RJ45 x 1

Dual Screen Splicing for More Content, 32:9 Ratio Available

Wall mounting can achieve seamless splicing of dual screens. superwide screen with 32:9 ratio, Interaction operation experience.

Various Options

Floating bracket/ streamlined bracket

SPECIFICATIONS
Model TV 135” TV 163” TV 216”
Screen Size 135inch 163inch 216inch
System Android 8.0 Android 8.0 Android 8.0
Resolution 2K (1920*1080) 4K (3840*2160) 4K (3840*2160)
Size(mm) 3000*1687.5mm 3600*2025mm 4800*2700*35mm
Brightness 100-600cd/m²   100-600cd/m²   100-600cd/m²
Refresh Rate 2880Hz 2880Hz 2880Hz
Video Interface HDMIx3（2input 1output），USB 3.0x1， USB 2.0x2 HDMIx3（2input 1output），USB 3.0x1， USB 2.0x2 HDMIx3（2input 1output），USB 3.0x1， USB 2.0x2
Audio Interface External audio x1 External audio x1  External audio x1
Control Interface RJ45,USB-B,WiFi,Bluetooth,Infrared remote control ( optional)
 		 RJ45,USB-B,WiFi,Bluetooth,Infrared remote control ( optional) RJ45,USB-B,WiFi,Bluetooth,Infrared remote control ( optional)
Install/Maintain Wall mounted, stacking, /frontservice Wall mounted, stacking, /frontservice Wall mounted, stacking, /frontservice
Note: For more product materials, please contact us directly.
